1350 X 1450MM Pallet Class Single Motor Single Motor Forklift Extended Forks

Name: 1350 X 1450MM Pallet Class Single Motor Single Motor Forklift Extended Forks
Brand: HUAHENG
Price: 15000 USD

Cheap 1350 X 1450MM Pallet Class Single Motor Single Motor Forklift Extended Forks for sale

Certification : ISO, CE

MOQ : 1

Price : 15000

Place of Origin : CHINA

Brand Name : HUAHENG

Model Number : HFTB230x70x165

Model NO. : HFTB230x70x165-1350*1450

Application : Loading, Forging

Condition : New

Warranty : 1 Year

No-Load Maximum Speed : 0-40m/Min

Maximum Speed at Full Load : 0-30m/Min

No-Load Acceleration : 1m/S^2

Full Load Acceleration : 0.5m/S^2

Color : Red/Black White

Total Fork Height : 576mm

Mounting Height : 189mm

Fw Fork Width : 186mm

Twf Fork Width : 716mm

Transport Package : Wooden Case

Trademark : HUAHENG

Origin : China

HS Code : 8428909090

Production Capacity : 3000

Packaging Details : Wooden box

Delivery Time : 30 workdays

Payment Terms : L/C,D/A,D/P,T/T,Western Union,MoneyGram

Contact Now

Hftb230X70X165-1350*1450pallet Class Single Motor Double Deep Position Highly Efficient Single-Motor Fork

Technical specialties

The HFTB230x70x165 series is a commonly used single-motor, double-deep fork for automated warehouse storage of standard pallet sizes from 1000mm to 1400mm.

Main components and functions:

One-piece upper fork: made of high-strength plate with integral bending processing, simple and beautiful, high strength;
High-strength needle roller bearings: customized according to the requirements of telescopic fork industry, with high precision, low resistance, strong radial bearing capacity, high hardness and self-aligning function, wear-resistant and impact-resistant;
Polymer material guide block: ultra-high polymer polyethylene, high wear-resistant, impact-resistant, with self-lubrication;
Analyzed chain: anti-stretch, high strength, high breaking load, fatigue resistance;
One-piece center fork: made of high-quality steel, machining center one-piece molding, with high precision;
Torque limiter protection: the driving part is equipped with a torque limiter, disc spring friction plate structure, overload slipping in time to disconnect the transmission;
Mechanical Limit Protection: The telescopic fork is equipped with a mechanical limit inside to prevent it from being dislodged over the stroke;
Drive: Variable frequency motor, AC servo motor with planetary reducer can be used to provide drive;
No-load maximum speed: 0-40m/min
Maximum speed at full load: 0-30m/min
No-load acceleration: 1m/S²
Full load acceleration: 0.5m/S²

1350 X 1450MM Pallet Class Single Motor Single Motor Forklift Extended Forks

FH Fork thickness (mm)	LS Cargo Length (mm)	L Fork Length (mm)	S1/S2 single/double deep stroke (safety stroke 30mm)	TH Total fork height (mm)	HC Mounting height(mm)	TWF Fork width (mm)	FW Fork width (mm)	Q Load (KG)	Single deep Load Disturbance(mm) ± 10%	Single deep No-Load Disturbance(mm) ± 10%	Dual deep Load Disturbance(mm) ± 10%	Double deep No-Load Disturbance(mm) ± 10%
80/175	1000	1200	1250+30/2350+30	552	247	>670	230	1500	16	≤5	44	≤8
	1100	1200	1300+30/2500+30					1500	16		45
	1150	1250	1350+30/2600+30					1500	16		46
	1200	1300	1400+30/2700+30					1200	16		47
	1250	1350	1450+30/2800+30					1200	17		48
	1300	1400	1500+30/2900+30					1000	17		49
	1350	1450	1550+30/3000+30					1000	17		50
	1400	1500	1600+30/3100+30					900	16	≤7	51	≤11
	1450	1550	1650+30/3200+30					800	17		52
	1500	1600	1700+30/3300+30					700	16		55

About us

Changsha Huaheng Robotics System Co., Ltd. is a global engineering company under Huaheng Group, which is committed to the development, design, manufacture and service of intelligent logistics and warehousing and intelligent manufacturing flexible automated production line, and a high and new technology enterprise that provides customers with integrated solutions of intelligent logistics and intelligent manufacturing.

The company has excellent design development and engineering technology team engaged in factory automation logistics industry for many years, after continuous independent research and development and innovation, the company has owned a number of patented technology certificates, the certificate covers intelligent manufacturing production line, intelligent three-dimensional warehouse, software control and so on. In the construction machinery industry for heavy industry enterprises to provide the world's leading outrigger, frame, boom, large-tonnage frame, large-tonnage boom five intelligent robot welding production line; for the world's advanced heavy industry enterprises to provide intelligent logistics large three-dimensional warehouse, marking the heavy industry oversized parts of the intelligent storage has been solved; in the pharmaceutical industry for the pharmaceutical factories to establish a multi-layer intelligent logistics sorting, picking project; in the real estate and construction industry The industry was the first to develop and implement the construction of four climbing frame intelligent robot welding production line to become the industry benchmark.
1350 X 1450MM Pallet Class Single Motor Single Motor Forklift Extended Forks

Telescopic forks are the actuators of the stacker cranes for accessing goods. The telescopic forks can be extended and retracted horizontally in order to feed (or remove) goods to and from the two side compartments. Forks generally use three-stage (or four-stage) linear differential telescopic forks, which are composed of cam bearings, slider guide units, power gear units, fork bodies, etc., and are driven by rack and pinion or chain.
